71
Chapter 2, Description of Connectors
Connectors
CDMA CLOCK MUX OUTPUT
The CDMA frame clocks provide the CDMA timing references for generating and
demodulating CDMA signals. The CDMA clock MUX output provides the
following CDMA frame clocks on a multiplexed output.
1.25 ms
20.00 ms
26.67 ms
80.00 ms
2.00 s
Each of these CDMA frame clocks is available by selecting from the list of
choices displayed on the CONFIGURE screen.
Operating Considerations
•BNC
• Select which frame clock will be output on the CDMA CLOCK MUX OUTPUT
connector by pressing the Config to select the CONFIGURE screen, then selecting the
Frame Clock field to display the list of choices.
• Nominal output level is >+5 dBm
• Output impedance is 50
Ω
• All frame clocks are locked to the Test Set’s timebase, internal or external. Refer to the
TimeBase field on the CONFIGURE screen.
See Also
Frame Clock
field description, on page 263
EVEN SEC INPUT
field description, on page 72
COMPOSITE VIDEO
The composite video output provides a signal for using an external video monitor.
The signal provides a duplicate of the Test Set’s screen.
Operating Considerations
•BNC
• A multi-sync monitor must be used to match the video sync rate of 19.2 kHz. Example
monitors include - Electrohome ECM 1410-DMS 14-inch color monitor and the EVM
1242-P4VID 12-inch monochrome monitor.
