441
Chapter 4, Description of Fields
Fields
Type
The Type field allows you to set the FOR_TRAFFIC and REV_TRAFFIC
parameters in the base station to ‘0’ (None), or ‘1’ (Primary). It appears only when
Service Option 6 or Service Option 14 are selected in the Traffic Data Mode field.
GPIB Example
“CDMA:CALL:TRAFfic:TYPE ‘None’“
Screens Where Field is Present
CDMA CALL CONTROL
CDMA RX TEST
CDMA TX TEST
CDMA RANGE TEST
Uniq Chall
NOTE: A Unique Challenge can be performed on the paging/access channels or on the traffic
channel.
When
Uniq Chall Execute is selected, this field sends an Authentication
Challenge Message to the mobile station, and the
SSD Update annunciator is lit.
In response, the mobile station sends back an Authentication Challenge Response
Message (including the parameter AUTHU).
If the Test Set does not receive the Authentication Challenge Response from the
mobile within 20 seconds, the Test Set will beep and the following message will
be displayed:
No mobile response to Unique Challenge. The SSD
Update
annunciator will be turned off.
If the Test Set receives the Authentication Challenge Response, it compares the
Received parameter AUTHU to its Expected (computed) AUTHU value. If the
values match, the
Status column is set to Passed and the message, Unique
Challenge on Paging [Traffic]: Passed.
is displayed in the
Authentication Data Table. The
Uniq Chall annunciator will be turned off.
GPIB Example
“CDMA:AUTH:UCH“
initiates a Unique Challenge-Response procedure.
