OPS1200 User’s Manual
30
OPS1200 INTERCONNECT WIRING
Digital Inputs / Outputs, Continued
XP4 -- Digital Inputs
Usage Pin Usage Pin
INP-00 1 INP-01 20
INP-02 2 INP-03 21
INP-04 3 INP-05 22
INP-06 4 INP-07 23
INP-08 5 INP-09 24
INP-10 6 INP-11 25
INP-12 7 INP-13 26
INP-14 8 INP-15 27
INP-16 9 INP-17 28
INP-18 10 INP-19 29
INP-20 11 INP-21 30
INP-22 12 INP-23 31
INP-24 13 INP-25 32
INP-26 14 INP-27 33
INP-28 15 INP-29 34
INP-30 16 INP-31 35
N/C 17 N/C 36
N/C 18 N/C 37
N/C 19
Table 3.8 OPS1200 Auxiliary Digital Input Connector
