Chapter 3, OPS1200 Hardware Interconnection
29
OPS1200 INTERCONNECT WIRING
Auxiliary Digital Inputs / Outputs (XP3 / XP4)
Auxiliary Digital I/O is optional on the OPS1200.
There are two 37 pin D-subs provided on the OPS1200 for the auxiliary digital I/O interface.
One of the 37 pin D-subs is used for the auxiliary 32 Digital Inputs and the second is used for
the auxiliary 32 Digital Outputs.
Refer to Figure 1 for connector location.
Note: XP3 and XP4 are 37-pin female D-subs.
XP3—Digital Outputs
Usage Pin Usage Pin
OUT-32 1 OUT-33 20
OUT-34 2 OUT-35 21
OUT-36 3 OUT-37 22
OUT-38 4 OUT-39 23
OUT-40 5 OUT-41 24
OUT-42 6 OUT-43 25
OUT-44 7 OUT-45 26
OUT-46 8 OUT-47 27
OUT-48 9 OUT-49 28
OUT-50 10 OUT-51 29
OUT-52 11 OUT-53 30
OUT-54 12 OUT-55 31
OUT-56 13 OUT-57 32
OUT-58 14 OUT-59 33
OUT-60 15 OUT-61 34
OUT-62 16 OUT-63 35
N/C 17 N/C 36
N/C 18 N/C 37
N/C 19
Table 3.7 OPS1200 Auxiliary Digital Output Connector
