OPS1200 User’s Manual
28
OPS1200 INTERCONNECT WIRING
Power Input (POWER INPUT)
POWER INPUT is the connection for the standalone power supply to the OPS1200. Refer to
the ACR1200 Hardware Manual for fuse location and details.
Refer to Figure 1 for connector location.
Note: POWER INPUT is a 4-pin male circular plug.
POWER PLUG
Standalone Power Connector
Usage Description Pin
+5VDC Standalone +5VDC 1
+12VDC Standalone +12VDC 2
-12VDC Standalone –12VDC 3
GROUND Standalone Ground 4
Table 3.6 OPS1200 Standalone Power Connector
