Chapter 3, OPS1200 Hardware Interconnection
25
OPS1200 INTERCONNECT WIRING
Digital Inputs / Outputs (P3)
There is one 37 pin D-sub provided on the OPS1200 for digital I/O interface. The 37 pin
D-sub is used for both the 16 Digital Inputs and 16 Digital Outputs. Refer to Figure 1 for
connector location.
Note: P3 is a 37-pin female D-sub.
P3
Usage Pin Usage Pin
INP-00 1 INP-01 20
INP-02 2 INP-03 21
INP-04 3 INP-05 22
INP-06 4 INP-07 23
INP-08 5 INP-09 24
INP-10 6 INP-11 25
INP-12 7 INP-13 26
INP-14 8 INP-15 27
N/C 9 OUT-32 28
OUT-33 10 OUT-34 29
OUT-35 11 OUT-36 30
OUT-37 12 OUT-38 31
OUT-39 13 OUT-40 32
OUT-41 14 OUT-42 33
OUT-43 15 OUT-44 34
OUT-45 16 OUT-46 35
OUT-47 17 N/C 36
N/C 18 N/C 37
N/C 19
Table 3.3 OPS1200 Digital I/O Connector
