Diagnostics
123
Diagnostics Menu
The diagnostics menu allows you to choose the diagnostics tests to be run
and provides you with important system information. Options on this menu, as
shown below, are described in the following pages.
Diagnostics
Printer Tests
The printer tests are used to check the print quality and printer operation.
The Printer Tests parameters are described below. (For test running
procedures, see page 255.)
• Shift Recycle. A sliding alphanumeric pattern that identifies missing or
malformed characters, improper vertical alignment, or vertical
compression.
DIAGNOSTICS
Printer Tests
Test Width
Paper Out
Dots
System
Memory
Print Statistics
Shift Recycle*
All E’s
E’s + TOF
All H’s
All Underlines
All Black
Shuttle Slow
Shuttle Fast
Shuttle Only
Phase Printer
217* (500 lpm)
123* (1000 lpm)
62* (1500 lpm)
(1 to 2000)
Paperout Adj.
Burnin Test
Print Error Log
Clear Error Log
E-Net Test Page
1
Full Width*
80 columns
40 dots*
(4-76 dots)
x
Megabytes On:
x.x
Hrs.
Print:
x.x
Hrs.
Print Strokes
Print Lines
11 inch Pages
1
If Ethernet adapter is present
Note Your Customer Service Engineer typically runs these tests. They are
described in more detail in the
LineJet Printers Maintenance Manual
.
