Operation
Follow these steps to select and play a
preset tone.
1. Press
TONE
.
TONE
and the current
tone’s number appear.
Note:
The first time you turn the
keyboard on, it automatically selects
the tone GRAND PIANO (No. 000).
2. To play a different tone, choose a
preset tone from the 200 TONES list
and enter its three-digit number on
the keypad. As you press the keys,
the selected digits appear.
Notes:
• You can select the next highest or
lowest numbered tone by simply
pressing
+
or
–
on the keypad.
• The names of tone numbers 000–
127 are marked to the right of the
keyboard’s display. The names for
tone numbers 128–167 appear in
the table below. Memory locations
168 199 are reserved for custom
tones that you create (see “Using
the Custom Tone Synthesizer” on
Page 20).
• Precede a single-digit number
with
0 0
. For example, to select
No. Tone
128 SYNTH PAD 1
129 SYNTH PAD 2
130 OCT PIANO
131 OCT HARP
132 12 STR GUITAR 1
133 JAZZ OCT GUITAR
134 OCT SAXOPHONE
135 TOUCH BASS
136 STRINGS PIANO
137 E. PIANO STRINGS
138 STEREO PIANO
139 12 STR GUITAR 2
140 BRASS FALL
141 BASS SLIDE
142 FEEDBACK GT
143 PIANO STRINGS
144 ECHO ORGAN
145 ROTARY ORGAN
146 CHORUSED EP
147 STRINGS GT
148 PAD ENS 1
149 PAD ENS 2
150 SEQUENCE 1
151 SEQUENCE 2
152 SYNTH PAD 3
153 SYNTH PAD 4
154 SYNTH PAD 5
155 SYNTH PAD 6
156 SYNTH PAD 7
157 SYNTH PAD 8
158 REVERSE ECHO
159 FAST TREMOLO
160
–
167 DRUM SET 1-8
No. Tone
