Chapter 3 Front-Panel Operation
Front-Panel Operation Overview
35
3
Front-Panel Operation Overview
The following section describes an overview of the front-panel keys before
operating your power supply.
• The power supply is shipped from the factory configured in the front-panel
operation mode. At power-on, the power supply is automatically set to
operate in the front-panel operation mode. When in this mode, the front-
panel keys can be used. When the power supply is in remote operation mode,
you can return to front-panel operation mode at any time by pressing the
(Local) key if you did not previously send the front-panel lockout
command. A change between front-panel and remote operation modes will
not result in a change in the output parameters.
• The power supply has two output ranges. This feature allows more voltage
at a lower current or more current at a lower voltage. The desired output
range is selected from the front panel or over the remote interfaces. The
8V
or
20V for the E3633A and 25V or 50V for the E3634A annunciator indicates
the presently selected range.
• When you press key (the
Limit annunciator blinks), the display of the
power supply goes to the limit mode and the present limit values will be
displayed. In this mode, you can also observe the change of the limit values
when adjusting the knob. If you press the key again or let the display
time-out after several seconds, the power supply will return the display to
the meter mode (the
Limit annunciator turns off). In this mode, the actual
output voltage and current will be displayed.
• The output of the power supply can be enabled or disabled from the front
panel by pressing key. When the output is off, the
OFF annunciator
turns on and the output is disabled.
• The display provides the present operating status of the power supply with
annunciators and also informs the user of error codes. For example, the
power supply is operating in CV mode in the 8V/20A* or 25V/7A** range and
controlled from the front panel, then the
CV and 8V* or 25V** annunciators
will turn on. If, however, the power supply is remotely controlled, the
Rmt
annunciator will also turn on, and when the power supply is being addressed
over GPIB interface, the
Adrs annunciator will turn on. See “Display
Annunciators’ on page 5 for more information.
Store
Local
Display
Limit
Display
Limit
Output
On/Off
*For Agilent E3633A Model **For Agilent E3634A Model
