Chapter 1
Introduction
WAP-4060PE is an IEEE 802.11g Wireless Access Point with PoE. Catering to the enterprise
demands, WAP-4060PE enhances security and management features, including multiple
SSIDs, VLAN support, WPA support, RADIUS MAC authentication, rogue AP detection, and so
on. The LAN port of WAP-4060PE is 802.3af compliant. Therefore, it can be installed anywhere
without the constraint on power socket. Provided with one reversed-polarity SMA male connec-
tor, WAP-4060PE is easy to connect external antenna and booster to extend the wireless
distance.
1.1 Package Contents
Make sure that you have the following items:
n WAP-4060PE
n Dipole Antenna
n Quick Installation Guide
n User’s manual CD-ROM
n Power Adapter
Note:
If any of the above items are missing, contact y
possible.
1.2 System Requirements
Before installation, please check the following requirements with your equipment.
n Pentium Based (And Above) IBM-Compatible PC System
n CD-ROM drive
n Windows 98/ME/2000/XP Operating System with TCP/IP protocol
1.3 Features
n Wireless LAN IEEE802.11g and IEEE802.11b compliant
n Support PoE port (IEEE802.3af compliant)
n Support IEEE802.11d standard (Worldwide mode)
n Strong network security with 802.1X authentication, and 64/128-bit WEP encryption
n Supports WPA (Wi-Fi Protected Access) for both 802.1x and WPA-PSK
n One detachable reverse-polarity SMA connectors can connect to external antenna for
expanding connection distance
n Super G mode efficiently raises the data transfer rate up to 108Mbps
n Five operation modes selectable: AP / AP Client / Wireless Bridge / Multiple Bridge / Re-
peater
n Adjustable output power level
n Support Multiple SSIDs, Multiple SSID isolation, 802.1Q VLAN, RADIUS MAC authentica-
tion, Rogue AP detection, Access Control
