33
In PTMP mode,
only allow
specified APs
This is only functional if using Point-to-Multi-Point Bridge (PTMP)
mode. If enabled, you can specify the MAC addresses of the
APs which are allowed to connect to this AP. To specify the
allowed APs:
1. Enable this checkbox
2. Click the button "Set PTMP APs".
3. On the resulting sub-screen, enter the MAC addresses of the
allowed APs.
Set PTMP APs
Use this to open a sub-window where you can specify the MAC
addresses of the APs which are allowed to connect to this AP.
This is only functional if using Point-to-Multi-Point Bridge (PTMP)
mode and you has enabled the checkbox "In PTMP mode, only
allow specified APs".
Parameters
Channel No
· If "Automatic" is selected, the WAP-4060PE will select the
best available Channel.
· If you experience interference (shown by lost connections
and/or slow data transfers) you may need to experiment with
manually setting different channels to see which is the best.
Current Chan-
nel No.
This displays the current channel used by the WAP-4060PE.
3.8.2 Advanced Settings
Clicking the Advanced link on the menu will result in a screen like the following.
