Operating Instructions
50
Table 3-7 GP-IB Commands
Command
*Range or **Response
To Query Description Page
VSET x
VSET xV
Agilent 6030A *0--204.75 V
Agilent 6031A *0--20.475 V
Agilent 6032A *0--61.425 V
Agilent 6033A *0--20.475 V
Agilent 6035A *0--511.88 V
Agilent 6038A *0--61.425 V
Any of these commands is used to program
output voltage. Initial Condition: 0 V
55
VSET xMV Agilent 6030A *0--204750 mV
Agilent 6031A *0--20475 mV
Agilent 6032A *0--61425 mV
Agilent 6033A *0--20475 mV
Agilent 6035A *0--511880 mV
Agilent 6038A *0--61425 mV
ISET x
ISET xA
Agilent 6030A *0--17.403 A
Agilent 6031A *0--122.85 A
Agilent 6032A *0--51.1875 A
Agilent 6033A *0--30.7125 A
Agilent 6035A *0--5.119 A
Agilent 6038A *0--10.2375 A
Any of these commands is used to program
output current. Initial Condition: 0 A
56
ISEFT xMA Agilent 6030A *0--17403 mA
Agilent 6031A *0--122850 mA
Agilent 6032A *0--51187.5 mA
Agilent 6033A *0--30712.5 mA
Agilent 6035A *0--5119 mA
Agilent 6038A *0--10237.5 mA
VSET?
ISET?
**VSET xx.xxx
**ISET xx.xxx
Used to read voltage and current settings 56
VOUT?
IOUT?
**VOUT xx.xxx
**IOUT xx.xxx
Used to measure and read output voltage
or current.
56
OVP? **OVP xx.xx Causes power supply to measure OVP
setting (which is hardware set at front panel).
57
VMAX x
VMAX xV
VMAX xMV
(Same as VSET) Any of these commands is used to program an
upper limit (soft limit) on the voltage
programming value that the power supply will
accept.
57
IMAX x
IMAX xA
IMAX xMA
(Same as ISET) Any of these commands is used to program an
upper limit (soft limit) on the current
programming value that the power supply will
accept.
57
VMAX?
IMAX?
**VMAX xx.xxx
**IMAX xx.xxx
Used to read voltage and current limits (soft
limits).
57
