Chapter 6
Replaceable Parts
E3632-60002 Main PC Assembly
105
6
Reference
Designator
Agilent Part
Number
Qty Part Description Mfr.
Code
Mfr. Part Number
CR12 1901-1227 6 DIODE SWITCHING 75V 200MA 6NS TO-236 02910 BAS16
CR13 1901-1335 4 DIODE-PWR RECT 400V 1A 50NS 02037 MURS140T3
CR14 1884-0332 5 THYRISTOR-SCR TO-220AB VRRM=200 02037 MCR264-00
CR15 1901-1335 DIODE-PWR RECT 400V 1A 50NS 02037 MURS140T3
CR16 1906-0291 DIODE-DUAL 70V 100MA TO-236AA 02037 BAV99LT1
CR17-19 1884-0332 THYRISTOR-SCR TO-220AB VRRM=200 02037 MCR264-00
CR20 1901-1335 DIODE-PWR RECT 400V 1A 50NS 02037 MURS140T3
CR21-22 1901-1227 DIODE SWITCHING 75V 200MA 6NS TO-236 02910 BAS16
CR24 1901-1335 DIODE-PWR RECT 400V 1A 50NS 02037 MURS140T3
CR23 1906-0291 DIODE-DUAL 70V 100MA TO-236AA 02037 BAV99LT1
CR25 1902-0579 DIODE-ZNR 5.1V 5% PD=1W IR=10UA 02037 1N4733ARL
CR26 1906-0291 DIODE-DUAL 70V 100MA TO-236AA 02037 BAV99LT1
CR27 1901-1227 DIODE SWITCHING 75V 200MA 6NS TO-236 02910 BAS16
CR28 1884-0332 THYRISTOR-SCR TO-220AB VRRM=200 02037 MCR264-00
CR29 1906-0291 DIODE-DUAL 70V 100MA TO-236AA 02037 BAV99LT1
CR30 1902-0579 DIODE-ZNR 5.1V 5% PD=1W IR=10UA 02037 1N4733ARL
CR31 1906-0291 DIODE-DUAL 70V 100MA TO-236AA 02037 BAV99LT1
CR32-33 1901-1227 DIODE SWITCHING 75V 200MA 6NS TO-236 02910 BAS16
CR34-36 1906-0291 DIODE-DUAL 70V 100MA TO-236AA 02037 BAV99LT1
CR37-38 1906-0261 2 DIODE-CT-RECT 150V 16A 02037 SUR107CT
E1 9164-0173 1 ALARM-AUDIBLE PIEZO ALARM PIN TYPE; 25V 09939 PKM22EPP-4002 S
E2-7 9170-1431 6 CORE -SHIELDING BEAD 06352 HF50ACB-453215
E8 9170-1506 1 CORE-SHIELDING BEAD 06352 HF50ACB201209
F1-2 0699-2715 2 RESISTOR-FUSE 1 OHM +-5%; 0.5 W @70 01542 0699-2715
P1 1252-2161 1 CONN-RECT MICRORBN 24-CKT 24-CONT 01542 1252-2161
P2 1252-2266 1 CONN-RECT D-SUBMIN 9-CKT 9-CONT 01542 1252-2266
P3 1252-8092 1 CONN-POST TYPE 3.96-PIN-SPCG-MTG-END 01542 1252-8092
P4 1251-5066 1 CONN-POST TYPE 2.5-PIN-SPCG-MTG-END 01542 1251-5066
P5 1251-8363 1 CONN-POST TYPE .156-PIN-SPCG-MTG-END 01542 1251-8363
P6 1252-7162 1 CONN-POST TYPE 2.0-PIN-SPCG-MTG-END 01542 1252-7162
P7-10 1252-2771 4 CONNECTOR-SGL QDISC-M .25-IN-BSC-SZ 01542 1252-2771
P11 1252-8093 1 CONN-POST TYPE 3.96-PIN-SPCG-MTG-END 01542 1252-8093
Q1 1853-0525 1 TRANSISTOR PNP SI TO-236AA PD=200MW 02910 PMBT2907A
Q2 1854-1053 6 TRANSISTOR NPN SI SOT-23 (TO-236AB) 03406 MMBT2222A
Q3-4 1855-1660 2 TRANSISTOR MOSFET N-CHAN E-MODE
TO-247AC
03038 IRFP044N
Q5 1854-1053 TRANSISTOR NPN SI SOT-23 (TO-236AB) 03406 MMBT2222A
Q6 1853-0281 1 TRANSISTOR PNP 2N2907A SI TO-18 PD=400MW 02037 2N2907A
