Replaceable Parts 95
Table 5-6. A2 GPIB Board, Replaceable Parts (see Note)
Ref. Desig. Agilent Part No. Description
ELECTRICAL PARTS
C122 0180-4606
Capacitor 10,000µF
C128 0160-4281 Capacitor 2,200pF
F101 2110-0699 Fuse Subminature 5AM
J101 1252-2320 Connector Receptacle (GPIB)
J106 1251-4926 Connector Receptacle (Test Header)
J107, 108, 114, 115 1251-7330 Connector Receptacle
P101 1251-4245 Connector Plug 2-pin (AC Bias)
U110, U111 1990-0444 IC Optoisolator
U113 1990-0543 IC Optoisolator
U117 1820-2549 IC Optoisolator
U118 1820-4185 IC Optoisolator
U121 1820-0430 IC Voltage regulator
TB101 0360-2312 Terminal Block (Digital Control)
MECHANICAL PARTS
-- 1205-0758 Heatsink (U121)
-- 0535-0031 Nut hex w/lockwasher (J101)
-- 0515-0642 Screw (U121)
-- 0515-0911 Screw M3x0 5 (J101)
Note: All other parts are surface mounted and are not field repairable
Table 5-7. A3 FET Assembly, Replaceable Parts
Ref. Desig. Agilent Part No. Description
ELECTRICAL PARTS
C201 0160-7505 7uF+ - 5% 200V
C202 0180-4132 CAP 6.8uF 35V
C203 0160-4835 CAP .luF 10% 50V
C204, 205 0160-5098 CAP .22uF 10%
C206 0180-4132 CAP 6.8uF 35V
C207, 208, 209 0160-2006 CAP 100pF 10%
C210, 211, 213, 214, 0160-6838 CAP 2200pF lKV
C215, 216 0160-2006 CAP 100pF 10%
C217 0160-5098 CAP .22uF 10%
C218 0160-4835 CAP .luF 10% 50V
C219 0160-2006 CAP 100pF 10%
C220 0180-4132 CAP 6.8uF 35V
C221 0160-5098 CAP .22uF 10%
C222 0180-4132 CAP 6.8uF 35V
C226 0160-4791 CAP 10pF 5% 100V
C227 0160-4835 CAP .luF 10% 50V
C228 0160-2301 CAP 2000pF 100V
C229 0160-4918 CAP .022uF 50V
C230 0160-4831 CAP 4700pF 10%
C231 0160-2301 CAP 2000pF 100V
C235, 236, 237, 238 0160-4832 CAP .0luF 10%
C239 0160-4791 CAP 10pF 5% 100V
C240 0160-4832 CAP .0luF 10%
C242, 243 0160-5098 CAP .22uF 10%
