Replaceable Parts 105
Table 5-14. A10 Control Assembly, Replaceable Parts
Ref. Desig. Agilent Part No. Description
ELECTRICAL PARTS
C500, 501, 502 0180-4129 CAP luF 35V
C503 0160-4835 CAP .luF 10% 50V
C504 0180-4129 CAP luF 35V
C505 0180-4131 CAP 4.7uF 35V
C506 0160-4835 CAP .luF 10% 50V
C507 0180-4136 CAP l0uF 20V
C508 0160-4831 CAP 4700pF 10%
C509, 510 0180-4129 CAP luF 35V
C511 0160-5422 CAP .047uF 20%
C512 0160-5644 CAP .033uF 10%
C513 0160-4789 CAP 15pF 5% l00V
C514, 515 0160-4805 CAP 47pF 5% l00V
C516 0160-5422 CAP .047uF 20%
C517 0180-4129 CAP luF 35V
C518, 519 0160-4835 CAP luF 10% 50V
C520 0160-4822 CAP l000pF 5%
C521 0160-4832 CAP .0luF 10%
C530, 531, 532 0160-5422 CAP .047uF 20%
C533, 534, 534 0160-4801 CAP l00pF 5%
C536, 537, 538 0160-5422 CAP .047uF 20%
C539 0160-4846 CAP 1500pF l00V
C540, 541, 542, 543 0160-5469 C-F luF 10% 50V
C544 0160-4835 CAP .luF 10% 50V
C545, 546 0160-4801 CAP l00pF 5%
C547 0180-2264 C-F 3.3uF 15V
C548
6680A, 6681A 0160-4855 CAP 0.1uF 50V
C556, 560 0160-4835 CAP .luF 10% 50V
C561 0160-4904 CAP 6800pF 5%
C562 0160-4791 CAP l0pF 5% l00V
C563, 564 0160-4835 CAP .luF 10% 50V
C565 0160-4791 CAP l0pF 5% 100V
C566 0160-4795 CAP 4.7pF
C567 0160-4904 CAP 6800pF 5%
C568, 569 0160-4787 C-F 22pF 5% l00V
C570 0160-4795 CAP 4.7pF
C571 0180-4129 CAP luF 35V
C572 0180-4131 CAP 4.7uF 35V
C573 0160-4835 CAP .luF 10% 50V
C574 0160-4805 CAP 47pF 5% l00V
C575, 576 0160-5098 CAP .22uF 10%
C577, 578 0160-4824 CAP 680pF l00v
C579, 580 0160-4835 CAP .luF 10% 50V
C581 0160-4797 CAP 3.3pF
C583 0160-4807 CAP 33pF 5% l00V
C584 0160-4797 CAP 3.3pF
C585 0160-4834 CAP .047uF 10%
C586 0160-4835 CAP .luF 10% 50V
C587
6680A 0160-4814 CAP 150pF 5%
6681A 0160-4801 CAP l00pF 5%
6682A, 683A, 6684A 0160-4813 CAP 180pF 5%
