Replaceable Parts 113
Table 5-14. A10 Control Assembly, Replaceable Parts (continued)
Ref. Desig. Agilent Part No. Description
R709
6680A 0757-0468 RES 130K
6681A, 6682A 0757-0464 RES 90.9K
6683A, 6684A 0757-0464 RES 90.9K
R710
6680A 0698-5091 RES 45K
6681A, 6682A 0698-3160 RES 31.6K
6683A, 6684A 0698-3160 RES 31.6K
R711 0698-5091 RES 45K
R712 0698-0082 RES 464 1% .125W
R713 0757-0442 RES 10K 1% .125W
R714 0757-0349 RES 22.6K 1%
R715 0757-0447 RES 16.2K 1%
R716 0698-3449 RES 28.7K 1%
R717
6680A, 6681A not used
6682A, 6683A, 6684A 0757-0442 RES 10K
R718 0698-3162 RES 46.4K 1%
R719 0757-0458 RES 51.1K 1%
R720 0698-8093 RES 40K .1% .lW
R721 0698-6630 RES 20K .1%
R724 0698-3279 RES 4.99K 1%
R725
6680A, 6681A not used
6682A, 6683A, 6684A 0757-0199 RES 21.5K
R726 0698-6359 RES 80K .1%
R727, 728 0698-6630 RES 20K .1%
R729 0698-6359 RES 80K .1%
R730, 731 0698-6630 RES 20K .1%
R732 0698-6619 RES 15K .1%
R733 0699-0489 RES 16.15K .1%
R734 0683-2255 RES 2.2M 5% .25W
R738 0698-8959 RES 619K 1%
R741
6680A 0757-0429 RES 1.82K
6681A 0698-3496 RES 3.57K
6682A 0757-0436 RES 4.32K
6683A 0698-3496 RES 3.57K
6684A 0698-3151 RES 2.87K
R742 0698-4509 RES 80.6K 1%
R743 0698-8093 RES 40K .1% .lW
R744 0683-0475 RES 4.7 5% .25W
R745 0698-6630 RES 20K .1%
RT500 0837-0397 Thermistor
S500 3101-1973 SW-SL 7-lA
U500 1826-2341 IC-REG TL7702BCP
U501, 502 1826-1370 IC 365
U503 1826-0346 IC OP AMP
U504 1826-1369 IC-VOLTAGE REG
