Front Panel Operation - 4
43
Press this key to access the phase menu list.
Display Command Function
PHASE <value> Set immediate output phase
PHASE:T <value> Set triggered output phase
PHASE:M <char> Select the phase mode (FIXED, STEP, PULSE or LIST)
Press this key to access the shape menu list.
Display Command Function
SHAPE <char> Select the immediate output wave shape (SINE,
SQUARE, or CSINE) CSIN = clipped sine wave
SHAPE:T <char> Select the triggered output wave shape (SINE, SQUARE,
or CSINE) CSIN = clipped sine wave
SHAPE:M <char> Select the shape mode (FIXED, STEP, PULSE or LIST)
CLIP <value> Set the clipping level of the CSIN wave shape. This
specifies the point where clipping starts as a percentage of
the peak amplitude or percentage of THD.
Press this key to access the pulse menu list.
Display Command Function
WIDTH <value> Set the pulse width
COUNT <value> Set the number of output pulses
DCYCLE <value> Set the pulse duty cycle as a percentage of the pulse period
PER <value> Set the pulse period
HOLD <char> Set the parameter that will be held constant as the other
parameters change (WIDTH or DCYCLE)
Press this key to access the output menu list.
Display Command Function
OUTP:COUP <char> Select output coupling (AC or DC)
*RST Execute *RST command to place the ac source in the
factory-default state
TTLT:SOUR <char> Select Trigger Out source coupling (BOT, EOT or LIST)
BOT = beginning of trensient
EOT = end of transient
LIST = TTLT trigger (see Programming Guide)
TTLT:STATE <value> Set Trigger Out state (ON or OFF)
IMP:STATE <value> Set output impedance programming (ON or OFF)
IMP:REAL <value> Set real part of output impedance
IMP:REAC <value> Set reactive part of output impedance
PON:STATE <char> Select power-on state command (RST or RCL0)
RI <char> Sets remote inhibit mode (LATCHING, LIVE, or OFF)
DFI <char> Sets discrete fault indicator state (ON or OFF)
DFI:SOUR <char> Select the DFI source (QUES, OPER, ESB, RQS, or OFF)
(see
Chapter 4 of Programming Guide)
Notes:
value = a numeric value
char = a character string parameter
and scroll through the command list.
and scroll through the parameter list.
Shift Phase
Shape
Pulse
Shift Output
