COPYRIGHT © 2006 MERIT ENTERTAINMENT
9 MEGATOUCH GAMETIME OWNER’S MANUAL PM0503-10
Diagnostics Menu
FIGURE 6 - DIAGNOSTICS MENU
Video Test Touch the screen to cycle through a series of video test screens.
I/O Test
Tests the SETUP and CALIBRATE buttons. A green light next to the
appropriate button will register each time that item is tested, and the
number next to the item should increment by one with each test. The
I/O Test Screen also displays which DIP switches are on or off.
NOTE: The DIP switch on/off status feature does not apply for
Gametime.
Touchscreen
Calibration
Follow the on-screen instructions to calibrate the touchscreen.
Touchscreen Test
Allows you to check the touchscreen calibration accuracy. The
crosshairs should follow your finger exactly when you move it across the
screen. If the crosshairs do not accurately follow, you should perform a
touchscreen calibration.
View System Log
Displays a log of all operations performed by the game since the log
was last cleared. This information is helpful for customer service
when troubleshooting your game.
Checksum Test
Checks the hard drive for missing or corrupted files. With
STOP ON
ERROR?
set to
YES
, a message indicating which file is corrupted will
be shown whenever the game encounters an error. With
STOP ON
ERROR?
set to
NO
, a list of corrupted files will be displayed when the
test is complete. If errors are detected, the software on the drive may
need to be reloaded. If this does not solve the problem, the drive may
require replacement. The test could take up to 30 minutes.
System Info
Gives details about the following:
• processor type and speed
• motherboard manufacturer
• amount of memory
•
Ethernet card manufacturer
• sound chip type
• video chip type
• touchscreen manufacturer
• hard drive manufacturer
and capacity
• modem part identification
number
• fan speed
• status
•
PSOC version
Verify Databases
Only use on the advice of Merit Technical Service. An
Update From
Server
must be performed prior to verifying databases.
