198 SANRAD V-Switch User Manual
init
This command initializes the most basic V Switch parameters needed to
begin managing the V Switch operations via the management port. This
command is executed via RS232 connection to a console.
This command can only be executed once. This command is unavailable
once the basic V Switch parameters are set.
If the V Switch management IP address and mask are set using the LED, the
V Switch name is set to the default V Switch and this command will not
be available. Use the CLI command device set to change the basic V
Switch parameters.
init
SWITCH PARAMETER DEFINITION STATUS EXAMPLE
-n
NAME USER-ASSIGNED
NAME FOR THE V
S
WITCH
MANDATORY
VSwitch1
-ip
MANAGEMENT IP
ADDRESS
IP
ADDRESS OF
THE MANAGEMENT
PORT
MANDATORY
212.199.43.46
-im
MANAGEMENT IP
MASK
IP M
ASK FOR THE
MANAGEMENT PORT
OPTIONAL
DEFAULT:
255.255.255.0
-p
UDP PORT PORT THROUGH
WHICH ALL
UDP
COMMUNICATIONS
WILL FLOW
–
NAMELY FOR SNMP
OPTIONAL
DEFAULT: 161
-if
INTERFACE ALIAS ALIAS OF
MANAGEMENT
INTERFACE
OPTIONAL
DEFAULT :
ETH1
Example
init –n VSwitch1 –ip 212.199.43.46
admin show
This command shows all valid user login names for the V Switch.
admin show
Table 31: Administrator User Names
User Name
Joe Cool
Cyber Dude
