14. General Information
109
14 General InformationPrinted Reports
14.1 Reference lists and reports
You can print out the following lists and reports for your
reference.
– “Setup List”
– “Tel No. List”
– “Journal Report”
– “Broadcast List”
– “Printer Test”
– “Caller ID List”
– “PCL Font List”
– “Address List”
– “FTP Server List”
1 {Menu}
2 Press {V} or {^} repeatedly to select “Print
Report”.
3 Press {<} or {>} repeatedly to select the desired
item.
4 Press {Set} to start printing. i {Menu}
Specifications
14.2 Specifications
{Set} {V}{^}{<}{>}
{Menu}
■ Applicable lines:
Public Switched Telephone Network
■ Document size:
Max. 216 mm in width, Max. 600 mm in length
■ Effective scanning width:
208 mm
■ Effective printing width:
A4: 202 mm
Letter/Legal/216 mm × 330 mm/216 mm × 340 mm:
208 mm
■ Transmission time
*1
:
Approx. 4 s/page (ECM-MMR Memory transmission)
*2
■ Scanning density:
Scanning resolution:
Up to 600 × 2,400 dpi (Optical)
Up to 9,600 × 9,600 dpi (Interpolated)
Copy resolution:
Up to 600 × 600 dpi
Fax resolution:
Horizontal: 8 pels/mm
Vertical: 3.85 lines/mm-in standard resolution,
7.7 lines/mm-in fine/photo resolution,
15.4 lines/mm-in super fine resolution
■ Photo resolution:
64-level
■ Scanner type:
Colour Contact Image Sensor
■ Printer type:
Laser Printer
■ Data compression system:
Modified Huffman (MH), Modified READ (MR), Modified
Modified READ (MMR)
■ Modem speed:
33,600 / 31,200 / 28,800 / 26,400 / 24,000 / 21,600 /
19,200 / 16,800 / 14,400 / 12,000 / 9,600 / 7,200 / 4,800
/ 2,400 bps; Automatic Fallback
■ Operating environment:
10 °C – 32.5 °C, 20 % – 70 % RH (Relative Humidity)
■ Dimensions:
Approx. width 530 mm × depth 460 mm × height 480 mm
■ Mass (Weight):
Approx. 24 kg
■ Power consumption:
Standby: Approx. 8.0 W
Preheat: Approx. 80 W
Copy: Approx. 600 W
Maximum: Approx. 1,200 W (When the fuser lamp turns
on)
■ Power supply:
220–240 V AC, 50/60 Hz
■ Memory capacity
(for operation and storing memory):
128 MB
