Introduction
To order parts, call the Nordson Finishing Customer Support Center at (800)433-9319 or your local Nordson
representative. Use the parts lists and illustrations to locate and describe parts correctly.
Using the Illustrated Parts List
Numbers in the Item column correspond to numbers that identify parts in illustrations following each parts
list. The code NS (not shown) indicates that a listed part is not illustrated. A dash (—) is used when the part
number applies to all parts in the illustration.
The number in the Part column is the Nordson Corporation part number. A series of dashes in this column
(- - - - - -) means the part cannot be ordered separately.
The Description column gives the part name, as well as its dimensions and other characteristics when
appropriate. Indentions show the relationships between assemblies, subassemblies, and parts.
S If you order the assembly, items 1 and 2 will be included.
S If you order item 1, item 2 will be included.
S If you order item 2, you will receive item 2 only.
The number in the Quantity column is the quantity required per unit, assembly, or subassembly. The code
AR (As Required) is used if the part number is a bulk item ordered in quantities or if the quantity per
assembly depends on the product version or model.
Letters in the Note column refer to notes at the end of each parts list. Notes contain important information
about usage and ordering. Special attention should be given to notes.
Item Part Description Quantity Note
— 0000000 Assembly 1
1 000000
S Subassembly
2 A
2 000000
SS Part
1
