GLID 133
This function displays each servo’s operating value. Each bar
center indicates neutral position. Left or right dots indicate 50%,
100% and 150%.
Note: All indications are actual positions including adjustments
and mixing. It is also possible to view servo travel/servo
directions when mixing functions are activated.
4.18 Servo Output Indicator (Function Mode)
Press the UP and DN keys
simultaneously to enter/exit
the Function Mode
Press the DN and Select keys
simultaneously to access the
Function Mode List Display
50%
100%
150%
ATV Travel
DN
SELECT
CH CH CLEARUP
To Dual Rate
Exponential function
To Timer
function
