CHAPTER 1 Network Environment Setup and Tool Installation
1.6 Management Tool Operating Conditions and Use
17
C122-E175-01EN
Menu Bar
Description
French(Belgium)
Set to ‘French (Belgium)’.
Dutch(Belgium)
Set to ‘French.’
Russian(Russia)
Set to ‘Russian’.
Japanese(QWERTY)
Set to ‘Japanese (QWERTY)’.
Japanese(Hiragana)
Set to ‘Japanese (Hiragana)’.
Japanese(Katakana)
Set to ‘Japanese (Katakana)’.
Turkish - F
Set to ‘Turkish -F’.
Turkish - Q
Set to ‘Turkish -Q’.
Mouse
Show Cursor
Display cursor.
Mouse Calibration
Perform calibration of mouse location.
Show Host Cursor
Display host cursor.
Mouse Mode
Absolute mouse mode
Set a mouse to ‘Absolute mode’.
A mouse pointer in [Video redirection] window is adjusted
to absolute value of a mouse pointer in terminal PC.
Relative mouse mode
Set a mouse to ‘Relative mode’.
A mouse pointer in [Video redirection] window is adjusted
to relative position calculated by difference from previous
position of a mouse in terminal PC.
Hide mouse mode (*1)
Set a mouse to ‘Hide mode’.
This mode should be used if action of a mouse pointer in
[Video redirection] does not match with that in terminal
PC.
Options
Keyboard/Mouse Encryption
Encrypts keyboard data and mouse data.
Window Size
Actual Size
Return size of [Video redirection] window to normal size
(100%).
Fit to Client Resolution
Fit to resolution of client window.
Fit to Host Resolution
Fit to resolution of host window.
GUI Languages
DE - Deutsch
Set menu display to ‘German’.
EN - English
Set menu display to ‘English’.
JA -
日本語
Set menu display to ‘Japanese’.
Media
Virtual Media Wizard
Set virtual media.
Active Users
:
Display user who is performing video redirection.
Power (*2)
Power On
Power on a partition.
Immediate Power Off
Power off a partition immediately.
Power Cycle
After powering off a partition, power on a partition again.
Press Power Button
Press power button.
Immediate Reset
Perform hardware reset.
Pulse NMI
Issue NMI.
Graceful Reset (Reboot)
Perform Graceful Reset (Reboot).
Graceful Power off (Shutdown)
Perform Graceful Power off (Shutdown)
Set Boot Options
Perform setup of Boot Options.
Help
About JViewer
Display version information.
If you click the "About JViewer", it may take a few minutes
to appear the dialog box that displays the JViewer
information.
You cannot operate the video redirection in the meantime.
In such a case, please wait a while for the dialog box to
appear, or stop the javaw.exe task in task manager and
then restart the video redirection.
Server Information
Display information of server.
(*1) Set mouse mode to ‘Hide mouse mode’ when operate LSI WebBIOS since action of cursor in LSI
WebBIOS is adjusted to actual action of your mouse cursor.
