MP-4000 TH . Revision 1.2
33
Chapter 5
Technical Specifications
Characteristics Specification
Method: Direct thermal line printing
Printing Speed: 250 mm/s
Paper Feed Speed: 59 lps
Dot Density: 8 dots/mm (203 dpi x 203 dpi)
Paper Width (mm) Printing Width (mm)
58 48 (384 dots)
76 64 (512 dots) or 72 ( 576 dots)
80 Up to 76 (608 dots)
Printing Width:
82,5 Up to 80 (640 dots)
Characters per Line: 24, 32, 48 e 64
Printing Characteristics
Characters Set: CODE 437, CODE 850, CODE 858 and CODE 860
- Bar Codes: EAN-8, EAN-13, CODE 39, CODE 93, CODE 128, ITF, CODABAR, UPC-A, UPC-E, ISBN,
MSI, PLESSEY, PDF-417
- Cash Drawer Driver 01 driver (RJ-12 connector)
- Paper Tear Bar
- Automatic Cutter - partial and full cut (optional)
- Drop in paper loading
- Flash-based uploadable firmware
- Bit Map Image Buffer, uploadable logos and character sets
- Buzzer under software application control
- Selectable font styles (Normal, Double High, Double Wide, Double High & Wide, Emphasized, Bold,
Underscore, Italic, Inverted, Landscape)
- Communication Interfaces
(1)
: Serial (RS-232C), Parallel (IEEE1284), USB 2.0, Ethernet, WiFi
- Power Supply: 24VDC ± 10%, 2A (external power supply)
Features
- Sensors: Head Up Sensor, End of Paper Sensor, Near End Paper Sensor, Top Cover Sensor
Type: Single-ply thermal paper roll
Width: 58 to 82.5 mm
Diameter: Up to 102mm (4 inches)
Media
Thickness: 56 to 107 microns
Printer Head Service Lifetime 150 km
Reliability
Cutter Lifetime 2,5 million cuts
Operating temperature 0 a 50 ºC
Environment
Operating Humidity 10 a 90% RH (non condensing)
Physical Characteristics
Dimensions: 146 mm (height) x 150 mm (width) x 218 mm (depth)
Mass: 1.2 kg
Software and Drivers
Windows 95
(2)
/ 98
(2)
/ ME™
(2)
, NT 4.0™
(2)
, Windows2000™, Windows XP™, Linux CUPS™
(3)
.
Configuration and remote management software applicative.
Available
Accessories
(1)
Power Supply, Communication Cable, Paper Roll, Wall Mount Bracket
(1) Please contact Bematech to consult the availability of the interfaces, accessories and optional. Bematech reserves to the right to
alter the specifications without previous warning.
(2) It works only with Serial and Ethernet communication interfaces.
(3) It doesn't work with USB communication interface.
