Operational, Basic, and Advanced Parameters
A-121 41-001343-02 REV04 – 05.2014
Ring Tone Per-Line Settings
Ring Tone via Speaker During Active Calls Settings
Parameter –
lineN ring tone
(N is a line number from 1 to 9)
Configuration Files
aastra.cfg, <model>.cfg, <mac>.cfg
Description Sets the type of ring tone on the IP phone on a per-line basis. Ring tone can be set to one
of six distinct rings.
Note:
LineN is applicable to lines 1 through 9.
Format Integer
Default Value -1 (Global)
Range -1 (Global)
0 (Tone 1)
1 (Tone 2)
2 (Tone 3)
3 (Tone 4)
4 (Tone 5)
5 (Silent)
Example line1 ring tone: 3
Parameter –
ring audibly enable
Configuration Files
aastra.cfg, <model>.cfg, <mac>.cfg
Description Enables/disables the feature whereby the ring tone of an incoming call is played through
the IP phone’s speaker if a user is on an active call or in the process of dialing out.
Notes:
• Feature compatibility is dependant on the IP phone model (see Ring Tone via Speaker
During Active Calls on page 5-90 for more information).
• This feature is not supported when utilizing the headset audio mode.
• With this feature enabled and when the phone’s speaker is playing the incoming call’s
ring tone, call-waiting tones will not be played.
Format Boolean
Default Value 0 (disabled)
Range 0-1
0 (disabled)
1 (enabled)
Example ring audibly enable: 1
