Operational, Basic, and Advanced Parameters
41-001343-02 REV04 – 05.2014 A-18
Parameter –
alternate tftp path
Configuration Files
aastra.cfg, <model>.cfg, <mac>.cfg
Description Specifies a path name for which the configuration files reside on an alternate TFTP
server for downloading to the IP Phone.
Note:
Enter the path name in the form folderX\folderX\folderX. For example,
ipphone\6757i\configfiles.
Format String
Default Value Not Applicable
Range Up to 256 alphanumeric characters
Example alternate tftp path: configs\alternate
Parameter –
use alternate tftp
Configuration Files
aastra.cfg, <model>.cfg, <mac>.cfg
Description Enables or disables the alternate TFTP server. Valid values are "0" disabled and "1" enabled.
Format Not Applicable
Default Value 0
Range 0 or 1
Example use alternate tftp: 1
Parameter –
ftp server
Configuration Files
aastra.cfg, <model>.cfg, <mac>.cfg
Description The FTP server’s IP address or network host name. This will become effective after this con-
figuration file has been downloaded into the phone.
Optional: You can also assign a username and password for access to the FTP server. See
the following parameters for setting username and password.
Note:
For DHCP to automatically populate this parameter, your DHCP server must support
Option 66.
Format IP address or fully qualified Domain Name
Default Value 0.0.0.0
Range Not Applicable
Example ftp server: 192.168.0.131
