August, 2006 SERVICE PROGRAM TABLES
5-175
T:PrtPGS/Col Mode [0~9999999/ 1]
8 491
These SPs count by color mode the total number of pages output
by the Copy, document server, and Fax applications.
C:PrtPGS/Col Mode [0~9999999/ 1] 8 492
These SPs count by color mode the total output by the Copy
application only
L:PrtPGS/Col Mode [0~9999999/ 1] 8 496
These SPs count by color mode the total output from within the
document server mode window at the operation panel.
8 496 1 B/W
8 496 2 Single Color Color MFP/2-color MFP machines only.
8 496 3 Two Color Color MFP/2-color MFP machines only.
8 496 4 Full Color Color MFP machines only
Notes for SP8 491 to SP8 496
• These SPs apply to the Copy, document server, and Fax applications only. They
do not apply to the Print application.
• When the ACS feature is used to select the color settings automatically, the
results of the ACS execute is used to increment the appropriate counter.
• If a color stamp is selected for printing on a monochrome document, the count is
for B/W.
• If the output is black and white even if color print mode was selected, the pages
count as Full Color.
• The color mode selected for a document stored on the document server is
counted. (The color selection cannot be changed once the document is stored on
the document server.)
T:PrtPGS/Col Mode [0~9999999/ 1]
8 501
These SPs count by color mode the total number of pages printed.
8 501 1 B/W
8 501 2 Single Color Color MFP and 2-Color MFP machines only.
8 501 3 Full Color Color MFP and Color LP machines only.
P:PrtPGS/Col Mode [0~9999999/ 1] 8 504
These SPs count by color mode the number of pages printed with
the Print application.
8 504 1 B/W
8 504 2 Single Color Color MFP and 2-Color MFP machines only.
8 504 3 Full Color Color MFP and Color LP machines only.
NOTE: At the present time, 8 501 and 8 504 perform identical counts, because
they are both limited to the Print application.
