Part II Playing the rhythm
43
QQTG0701
Playing the rhythm
Playing the rhythm
Intro, fill-in and ending patterns fitting each different rhythm pattern are permanently recorded in your PR,
thus allowing a versatile rhythm performance.
INTRO
Begin the rhythm performance with an intro pat-
tern.
1.
Press the INTRO & ENDING 1 or INTRO &
ENDING 2 button to turn it on.
2.
Press the START/STOP button to start the
rhythm.
• An intro pattern is played, after which the normal rhythm
pattern begins.
COUNT INTRO
You can begin the rhythm performance with a
spoken one-measure count.
1.
Press the COUNT INTRO (FILL IN 2) button
to turn it on.
2.
Press the START/STOP button to start the
rhythm.
• A spoken one-measure count is played, after which the
normal rhythm pattern begins.
Ⅲ
ⅢⅢ
Ⅲ
Mode setting
You can select the mode for the count sound.
1.
Press the MODE button in the AUTO PLAY
CHORD section to turn it on.
• The display looks similar to the following.
2.
Use the COUNT INTRO button to select a
mode.
VOICE: A spoken count (initialized setting).
CLICK: A clicking sound for the count.
FILL IN
You can insert a fill-in pattern any time during the
rhythm performance. Choose from two different
fill-in patterns.
1.
Select a rhythm and press the START/STOP
button.
2.
Press the FILL IN 1 or FILL IN 2 button.
• A fill-in pattern is heard immediately for the remainder of
the measure.
• When a FILL IN button is pressed on the last beat of the
measure, the fill-in pattern continues to the end of the fol-
lowing measure.
MAIN
VOLUME
MAX
MIN
MAX
OFF
AUTO PLAY CHORD
RHYTHM GROUP
TEMPO / PROGRAM
PROGRESSIVE
PIANIST PIANO STYLIST
SPLIT
POINT
METRONOME
POP ROCK
FUNK &
SOUL DISCO
POP BALLAD
BALLAD
BALLROOM
& SHOW
MEMORY
CONTRAST
LATIN &
WORLD
JAZZ &
SWING
WALTZ
& TRADUSA16 BEAT8 BEAT
IN OUT
SOUND
ARRANGER
SET
MODE
CHORD FINDER
OFF/ON
ONE TOUCH
PLAY
APC/SEQUENCER
VOLUME
DEMO
MUSIC STYLE ARRANGER
VARIATION
1 2 1 2 1 1 2 3 4BEAT
LOAD
SEQUENCER
RESET
COUNT
INTRO
234
FADE
FILL IN INTRO & ENDING
SYNCHRO & BREAK
START / STOP TAP TEMPO
HELP
OTHER PARTS/TR
-
TRANSPOSE
+
MUTE
PAGE
DISPLAY HOLD
EXIT GRAND
UPRIGHTELECTRIC
MODERN SIMPLE PIANO TECHNI-CHORDBANK
AB
C
P.MEM 5-8
SET 1 / 5 2 / 6 3 / 7 4 / 8
SOUND GROUP
SEQUENCER
PIANO
STRINGS
BASS
MALLET &
ORCH PERC
WORLD
PIANO
MIXTURES
ORCH
MIXTURES
DIGITAL
DRAWBARS
DRUM KITS
MEMORY
LEFT RIGHT 2 RIGHT 1
DIGITAL
EFFECT
MULTI
EFFECT
CHORUSREVERB
CHORD STEP REC
VOCAL
GUITAR &
HARPSIBRASS PLAY
EASY
REC
FAVORITES
PROGRAM
MENUS
DISK
IN USE
DISK
LOAD
SAX &
WOODWIND
ORGAN &
ACCORDION
SYNTH
SOUND
EXPLORER
CONDUCTOR
PANEL MEMORY
12
INTRO & ENDING
2
COUNT
INTRO
FILL IN
AUTO PLAY CHORD
MODE
CHORD FINDER
OFF/ON
12
SEQUENCER
RESET
COUNT
INTRO
FILL IN
