PORT-A-SAW SPECIFICATIONS (Model PS1411S Only)
MODEL NO. PS1411S **
TYPE
1-1/2 HP Electric (115 Volts)
Item No.
(with Water Pump)
M50114
Blade Guard
Capacity
10 – 14”
(250 – 350 mm)
Blade Shaft RPM
2150
Max. Depth Of Cut
5.0” (127 mm)
Blade Arbor Size
1.00” (25.4 mm)
Blade Shaft:
Sealed Ball Bearings
Blade Shaft Drive:
One 360J6 Poly-V Belt
Blade Guard:
One Piece Steel, Sta-Level™ Design, 14” (350 mm) Maximum Capacity
Blade Coolant:
Water
Water Pan:
3.86 x 17.73 x 30.73 Inch (98 x 450 x 780.5 mm), 6.75 Gallon (25 Liter) Capacity (At 3 ” Depth)
Conveyor Cart:
Cast Aluminum w/ Vulcanized Rubber Top, Adjustable Measuring Rule, 45° / 90° Cutting Guide
Water Pump:
PS1411S
Electric Model Only:
100 Gallons / Hour, Submersible, Totally Epoxy Sealed, Thermal Over Load Protected
Frame:
Heavy duty, Jig Welded “X” Braced Steel, Open Throat Design For Unlimited Ripping
Weight, Pounds (kg):
Saw Crated: 171 (77.7)
Saw Uncrated: 160 (72.7)
Saw Operating
(Water In Pan): 221 (100.5)
Folding Stand
(Unboxed): 24 (10.9)
Foot Pedal Kit
(Boxed): 14 (6.4)
Electric Cord: N / A
PORT-A-SAW POWER SOURCE
MODEL NO. SPS-1S **
TYPE
Electric
Engine / Motor:
Baldor
Horsepower (kw):
1-1/2 (1.1)
RPM:
1725
Specifications:
T.E.F.C
Voltage:
115
Cycle (Hz) / Current / Phase:
60 / A.C. / 1
Full Load Amps:
14.4 (at 115 V) **
Displacement:
------
Bore:
------
Stroke:
------
Cylinders / Cycle:
------
Fuel Capacity:
------
Oil Capacity:
------
Air Filter:
------
Starter:
Capacitor
Coolant:
Air
** Motor On PS1411S is designed to run on a 15 Amp Single
Phase Electrical Circuit (Household Electrical Current)
