4. MENU FUNCTION
10
–
DXC-C33/C33P Product Information Manual
Setting Items in the Menu
<EXPOSURE> [A]
>GAIN STEP
STEP 0dB
SHUTTER OFF
Select Back
<WHITE BALANCE> [A]
>MODE AWB
R. PAINT ± 0
B. PAINT ± 0
AREA NORMAL
Select Back
<CONTRAST> [A]
>EFFECT MANUAL
KNEE POINT MID
BLACK STRETCH ± 0
GAMMA ON
LEVEL ± 0
MASTER PEDESTAL ± 0
R. PEDESTAL ± 0
B. PEDESTAL ± 0
Select Back
• GAIN Adjusts the video gain
• STEP Sets the gain level
• SHUTTER Sets the electronic shutter modes
• SPEED Sets the shutter speed
• AE LEVEL Finely adjusts the focusing point of AE adjustment
• AE AREA 1 Sets the AE window in AGC or CCD IRIS or auto iris
AE AREA 2 adjustment mode
• AE SPEED Sets AE focusing speed in AGC or CCD IRIS or control
mode
• AE DETECT Sets the detection method of the luminance level of the
selected AE window
• MODE Selects white balance modes
• R./B. PAINT or
Finely adjusts the white balance (AWB, ATW)
•
R./B. GAIN
or manual white balance (MANU)
• EFFECT Adjusts the picture contrast in accordance with the
incident luminance level
• KNEE POINT Sets the Knee point
•
BLACK STRETCH
Adjusts the luminance of dark portions on the screen
• GAMMA Activates gamma compensation
• LEVEL Adjusts the gamma level
•
MASTER PEDESTAL
Sets the pedestal level of the output signal
• R./B. PEDESTAL Finely adjusts the pedestal level
