BRC-H900 Inquiry Command List (3/3)
Inquiry Command Command Packet Inquiry Packet Comments
VIDEO
OUT
D-SUB 15
FORMAT
- 8x 09 7E 01 03 FF y0 50 0p FF p: 0 RGB 1: YPbPr
ADD
SYNC(RGB)
- 8x 09 7E 01 07 FF y0 50 0p FF p: 0 RGB SYNC OFF 2: RGB
SYNCON
SYNC TYPE - 8x 09 7E 01 1A FF y0 50 0p FF p: 0 3-state SYNC 1: VD
IMG SIZE - 8x 09 7E 01 3C FF y0 50 0p FF p: 0 4: 3 [SQUEEZE] 1 16: 9
[LETTER] 2 4: 3 [CROP]
SETUP - 8x 09 7E 01 3F FF y0 50 0p FF p: 0 ON (7.5IRE) 1: OFF (0IRE)
BRBK-
SA1
D-SUB 9Pin
OUT1
- 8x 09 7E 01 24 0p FF y0 50 0q FF p: 0 Main Unit Card Slot 1 BRU-
SF10 Card Slot 1 2 BRU-SF10
Card Slot 2
q: 0 RGB 1 YCbCr
D-SUB 9Pin
OUT2
- 8x 09 7E 01 25 0p FF y0 50 0q FF p: 0 Main Unit Card Slot 1 BRU-
SF10 Card Slot 1 2 BRU-SF10
Card Slot 2
q: 0 Y/C 1 VBS
RGB SYNC - 8x 09 7E 01 26 0p FF y0 50 0q FF p: 0 Main Unit Card Slot 1 BRU-
SF10 Card Slot 1 2 BRU-SF10
Card Slot 2
q: 2 SYNC OFF 3 SYNC ON RGB
IMG SIZE - 8x 09 7E 01 27 0p FF y0 50 0q FF p: 0 Main Unit Card Slot 1 BRU-
SF10 Card Slot 1 2 BRU-SF10
Card Slot 2
q: 0 4: 3 [SQUEEZE] 1 16: 9
[LETTER] 2 4: 3 [CROP]
SETUP - 8x 09 7E 01 3B 0p FF y0 50 0q FF p: 0 Main Unit Card Slot 1 BRU-
SF10 Card Slot 1 2 BRU-SF10
Card Slot 2
q: 0 ON (7.5IRE) 1 OFF (0IRE)
BRBK-
HSD2
IMG SIZE - 8x 09 7E 01 43 0p FF y0 50 0q FF p: 0 Main Unit Card Slot 1 BRU-
SF10 Card Slot 1 2 BRU-SF10
Card Slot 2
q: 0 4: 3 [SQUEEZE] 1 16: 9
[LETTER] 2 4: 3 [CROP]
POWER
Status
ON/OFF
Inquiry
- 8x 09 7E 04 00 FF y0 50 0p FF p: 2 ON 3: OFF
CAMERA
Software
Ver si on
- - 8x 09 00 02 FF y0 50 00 01
mn pq rs tu vw FF
mnpq: Model Code (05xx)
rstu: ROM version
vw: Socket Number (02)
PRESET
Drive
Speed
- - 8x 09 7E 01 0B 0p FF y0 50 qq FF p: Preset number of speed retrieving
-1 (0-F)
qq: p position direction speed
response 01-18 (h)
TALLY - - 8x 09 7E 01 0A FF y0 50 0p FF p: 2 ON 3: OFF
PAN-TILT
Position
- - 8x 09 06 12 FF y0 50 Yp Yq Yr Ys
Yt Zp Zq Zr Zs FF
Yp Yq Yr Ys Yt Zp Zq Zr Zs: See
Pan/Tilt Position (for reference) in
the VISCA Command Setting
Values section
CAMERA
ID
- - 8x 09 04 22 FF y0 50 0p 0q 0r 0s FF pqrs: ID
TITLE
(Preset
Postion)
ON/OFF
Inquiry
- 8x 09 7E 01 17 FF y0 50 0p FF p: 2 ON 3: OFF
TITLE
Display
(Standard)
ON/OFF
Inquiry
- 8x 09 7E 01 13 FF y0 50 0p FF p: 2 ON 3: OFF
MENU
Display
Status
ON/OFF
Inquiry
- 8x 09 06 06 FF y0 50 0p FF p: 2 ON 3: OFF
PRESET - - 8x 09 04 3F FF y0 50 0p FF Return the last preset number which
has been operated (VISCA
parameters [0-F])
Zoom - - 8x 09 04 47 FF y0 50 0p 0q 0r 0s FF pqrs: See the VISCA Command
Setting Values (ZOOM) section
FOCUS - - 8x 09 04 48 FF y0 50 0p 0q 0r 0s FF pqrs: See the VISCA Command
Setting Values (FOCUS) section
