II-10
Setting Wipes
Chapter 2 Video Switching
Mixing operation
1
Press the AUX 1 bus delegation button.
2
Select a PGM in the PGM cross-point buttons.
3
Select the signal you want to mix in the PST/KEY
cross-point buttons.
4
Execute the transition using the fader lever, CUT
button, or AUTO TRANS button.
Aux1 and Aux2 settings are not stored in snapshots.
Setting Wipes
A wipe is a transition effect that switches to the next video
by applying an effect that removes the program output
video in a manner that appears as it is being wiped off with
the video to be output next.
With this unit, you can make the following settings.
• Selecting the Pattern and Direction for Wipes (page
II-11)
• Making Detailed Adjustments to Wipe Patterns (page
II-11)
• Adding the Edge to the Wipe Pattern (page II-12)
This section describes wipe effects and basic operations
for wipes.
Wipe settings are made in the [Effect] menu.
For details on the menu item, see “Details on [Effect] Menu” (page II-15).
The [Effect] menu does not appear in 3D mode.
Basic Operations for Wipe
Tip
Tip
Select the video for program output.
r
Select the next video for output.
r
Press the EFF transition type selection button.
r
Set the transition type to [Wipe].
r
Select the pattern and direction for the wipe.
r
Make detailed adjustments to the wipe pattern if necessary.
r
Execute the transition.
