127
Miscellaneous
5
Specifications
■ General
● Video Signal Protocol : PAL/NTSC
● Power Source and Voltage : Batteries: 6 volts
AC: 5 volts
● Dimensions (W × H × D) : 131.1 × 68.8 × 54.0 mm (5.17” × 2.71” × 2.13”)
(excluding grips)
● Weight : Approximately 350 g (12 oz.) (excluding batteries)
● Operating Range -
Temperature : 0° to 40° C (32° to 104 F)
● Operating Range - Relative
Humidity : 85% or less
● Storage : –20° to 60°C (–4° to 140°F)
■ Camera
● CCD : 2,310,000 million square pixels (effective: 2,160,000
million)
● Lens : Zoom lens F=3.2 - 3.7
• Focal length : f=8 - 24 mm (equivalent to 38-114 mm on 35mm
camera format)
• Minimum shooting range : Approximately 4.0 cm (1.6”) (macro)
● Viewfinder
• Type : Real image
• Magnification : Telescope 0.35X, standard 0.57X, wide angle 1.00X
• Parallax correction : No
• Diopter : –1 dpt
● Monitor
• Display Size : 1.8”
• Drive System : TFT Active Matrix System
• Picture Elements : Approximately 110,000 pixels
● White Balance : Auto/Preset (Daylight, Cloudy (Overcast),
Fluorescent Light, Tungsten Light)
● Exposure Compensation
• Light Metering System : Centerweighted
• Exposure Value Memory
System : Auto backlighting detection
Manual compensation, ±2.0 EV (in 0.5 EV
increments)
• Metering : TTL-CCD method
• Flash Automatic Exposure : Yes (daylight synchro)
• Shutter Speed : 1-1/500
• Minimum diaphragm setting : F 15.0 – F 17.2
• ISO Sensitivity : Approximately equivalent to 100
● Distance Adjustment
• Autofocus Method : TTL-CCD AF
• Autofocus Range : Approximately 4.0 cm (1.6”) to infinity
