TCP parameters will appear. These fields are explained later in this help file.
• IP Protocol Value
When "Specific" is selected for the IP protocol value, you can enter a specific
value.. The allowed range is 0 to 255. A frame that hits this ACE matches this IP
protocol value.
• IP TTL
Specify the Time-to-Live settings for this ACE.
• zero: IPv4 frames with a Time-to-Live field greater than zero must not be able
to match this entry.
• non-zero: IPv4 frames with a Time-to-Live field greater than zero must be
able to match this entry.
• Any: Any value is allowed ("don't-care").
• IP Fragment
Specify the fragment offset settings for this ACE. This involves the settings for the
More Fragments (MF) bit and the Fragment Offset (FRAG OFFSET) field for an
IPv4 frame.
• No: IPv4 frames where the MF bit is set or the FRAG OFFSET field is greater
than zero must not be able to match this entry.
• Yes: IPv4 frames where the MF bit is set or the FRAG OFFSET field is greater
than zero must be able to match this entry.
• Any: Any value is allowed ("don't-care").
• IP Option
Specify the options flag setting for this ACE.
• No: IPv4 frames where the options flag is set must not be able to match this
entry.
• Yes: IPv4 frames where the options flag is set must be able to match this
entry.
• Any: Any value is allowed ("don't-care").
• SIP Filter
Specify the source IP filter for this ACE.
• Any: No source IP filter is specified. (Source IP filter is "don't-care".)
• Host: Source IP filter is set to Host. Specify the source IP address in the SIP
Address field that appears.
• Network: Source IP filter is set to Network. Specify the source IP address and
source IP mask in the SIP Address and SIP Mask fields that appear.
• SIP Address
When "Host" or "Network" is selected for the source IP filter, you can enter a
specific SIP address in dotted decimal notation.
• SIP Mask
When "Network" is selected for the source IP filter, you can enter a specific SIP
mask in dotted decimal notation.
• DIP Filter
Specify the destination IP filter for this ACE.
• Any: No destination IP filter is specified. (Destination IP filter is "don't-care".)
• Host: Destination IP filter is set to Host. Specify the destination IP address in
the DIP Address field that appears.
• Network: Destination IP filter is set to Network. Specify the destination IP
