FGSW-2620VM / FGSW-2624SF Userโs Manual
FGSW-2624SF LED indication
๎ System
LED Color Function
PWR Green Lights to indicate that the Switch has power.
๎ Per 100Base-FX SFP slot
LED Color Function
LNK/ACT Green
Lights to indicate the link through that port is successfully established.
๎ Per 10/100/1000Base-T port /SFP interfaces
LED Color Function
LNK/ACT 1000 Green
Lit: indicate that the port is operating at 1000Mbps.
Off: indicate that the port is operating at 10Mbps or 100Mbps.
Blink: indicate that the switch is actively sending or receiving data over that port.
LNK/ACT 100 Green
Lit: indicate that the port is operating at 100Mbps.
Off: indicate that the port is operating at 10Mbps or 1000Mbps.
Blink: indicate that the switch is actively sending or receiving data over that port.
FDX Green
Lit: indicate that the port is operating at full-duplex mode.
Off: indicate that the port is operating at half-duplex mode.
1. Press the RESET button once. The t Switch will reboot automatically.
2. Press the RESET button for about 10 seconds. The Switch will back to the factory default
mode; the entire configuration will be erased.
3. The 2 Gigabit TP/SFP combo ports are shared with port 25/26 of FGSW-2620VM. Either of
them can operate at the same time.
12
