[Example]
PBX-1
QSIG
PBX-2
Dials "2000".
PBX-1
QSIG
PBX-2
Extn. 1000 Extn. 1001 Extn. 2000
Extn. 1000 Extn. 1001 Extn. 2000
Call to 2000
1
Transferred
to 1001
2
3
Extension 1000 of PBX-1 dials extension
number "2000", and the call is sent to
extension
"2000" of PBX-2 through QSIG
network.
The call is transferred from extension
2000 to extension "1001" of PBX-1.
The call between PBX-1 and PBX-2 is
released, and the call is connected
directly to the transfer destination of
extension 2000.
Conditions
• This feature can be enabled or disabled on an ISDN (QSIG) port basis.
• Call Transfer with Announcement and Call Transfer without Announcement is possible (® 3.1.8 Call
Transfer).
PC Programming Manual References
3.14 [1-1] Slot—Port Property - PRI Port (KX-TDA100/KX-TDA200/KX-TDA600 only)—Supplementary
Service—
COLP, CLIR, COLR, CNIP, CONP, CNIR, CONR, CF (Rerouting), CT, CCBS, E911
3.19 [1-1] Slot—Card Property - IP Gateway— QSIG-CT
3.35 [1-3] Option— New Card Installation—ISDN Standard Mode for PRI23 Card (KX-TDA100/
KX-TDA200/KX-TDA600 only)
Operating Manual References
1.3.11 Call Transfer
260 Feature Manual Document Version 2008-11
13.1.22 Private Network Features—QSIG—CT (Call Transfer)
