ENGLISH
SPECIFICATIONS
Super Audio CD Audio CD
Audio Characteristics
Analog output
Channels
2channels
2channels
Frequency range 2Hz — 100kHz 2Hz — 20kHz
Frequency characteristics 2Hz — 50kHz (-3dB) 2Hz — 20kHz
Dynamic range 112dB 100dB
THD (1kHz) 0.0020% 0.0020%
wow & flutter Precision of quartz Precision of quartz
Output level
Unbalanced 2.3V RMS stereo 2.3V RMS stereo
Digital output
output level (cinch JACK) — 0.5Vp-p (75Ω)
output level (optical) — -19dBm
Optical Readout System
Laser AlGaAs AlGaAs
Wave length 650nm 780nm
Signal format 1-bit DSD
16-bit linear PCM
Sampling frequency 2.8224MHz 44.1kHz
Power Supply
N Version ....................................................................................................... AC 230V 50Hz
Power Consumption ...................................................................................................... 19W
Cabinet, etc.
Dimensions (Width × Height × Depth) ............................................. 440 × 126.5 × 335.5mm
Net weight .................................................................................................................... 6.3kg
Net weight (SA7001 KI) ................................................................................................ 8.0kg
Operating temperatures ................................................................................. +5°C ~ +35°C
Operating humidity ............................................................................ 5 ~ 90% (without dew)
Accessories
• Remote control unit (RC7001SA) .................................................................................... 1
Dimensions (Width × Height × Depth) ................................................. 48 × 25.7 × 145mm
Net weight ..................................................................................................................160g
• AA Batteries ..................................................................................................................... 2
• AC Power cord .................................................................................................................1
• Audio cable ...................................................................................................................... 1
• Remote connection Cable................................................................................................ 1
• User’s Guide .................................................................................................................... 1
• Warranty Card.................................................................................................................. 1
Specifications subject to change without prior notice.
■ Dimensions (unit: mm)
SOUND MODE
SUPER AUDIO CD PLAYER SA7001
PROG
ALL TOTALSING
AMS
REMAIN SACD
RNDMTRK
A
–
B
1
1
TEXT
2345678 910 111213 1415 1617 1819 20
STEREO
SA7001: 16.5
SA7001 KI: 18.0
4.5
22.5
SA7001: 126.5
SA7001 KI: 128.0
110.0
440
SA7001: 335.5
SA7001 KI: 339.0
SA7001: 331
SA7001 KI: 334.5
SA7001: 331
SA7001 KI: 334.5
12
