TRACTOR- -MODEL NO. CTH180 XP (HAUCT18H42C), PRODUCT NO. 954 17 02-31
SCHEMATIC
BATTERY
STARTER
M
A
AMMETER
(OPTIONAL)
FUSE
FBI
SWITCH
BAG
INTERLOCK
FBI BUZZER
HOUR
METER
REGULATOR
IGNITION
UNIT
HEADLIGHTS
(OPTIONAL)
CARBURATOR SOLENOID
(IF SO EQUIPPED)
FUEL
LINE
ALTERNATOR
SPARK
PLUGS GAP
(2 PLUGS ON
TWIN CYL. ENGINES)
RELAY
85 86
30
87
87A
CLUTCH /BRAKE
(PEDAL UP)
PTO (DISENGAGED)
CG
F
H
B
E
A
D
SOLENOID
G
B
S
M
AI
A2
L
RED
RED
RED
RED
RED
RED
BLUE RED
BLUE
BROWN
WHITE
WHITE
ORANGE
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
ELECTRIC CLUTCH
28VOLTSAC@3600RPM(REGULATORDISCONNECTED)
CHARGINGSYSTEMOUTPUT
16AMPDC@3600RPM
NON-REMOVABLE
CONNECTIONS
REMOVABLE
CONNECTIONS
WIRING INSULATEDCLIPS
NOTE: IFWIRING INSULATED
CLIPS WEREREMOVED FOR
SERVICING OFUNIT, THEY
SHOULD BEREPLACED TO
PROPERLY SECUREYOUR
WIRING.
PTO SWITCH
CIRCUITPOSITION
OFF
C+F,B+E,A+DON
C+G,B+H
B
A
G
H
D
FC
E
87
87A
8586
30
RELAY
IGNITION SWITCH
CIRCUITPOSITION
OFF
B+A1RUN/LIGHT
B+S+A1START
M+G+A1
B+A1RUN
“MAKE”
A2+L
NONE
NONE
NONE
DIODE
SEAT SWITCH
(NOT OCCUPIED)
GROUNDING
CONNECTOR
