NOTE: You can specify the maximum permitted amount of skew at the front panel: select the
icon, then select Substrate handling options > Max skew setting.
5. Wait until the substrate emerges from the printer, as shown in the following graphic.
NOTE: If you have an unexpected problem at any stage of the substrate loading process, see
the Maintenance and troubleshooting guide.
6. The printer calibrates the substrate advance.
7. If you are loading transparent substrate without opaque borders, you are asked to enter the width
of the substrate and the distance of the right edge from the printer's side plate (as indicated by the
ruler on the front of the curing module).
8. The printer indicates that it is ready for printing.
Take care not to cover the fans.
If you have the take-up reel and want to use it, see Use the take-up reel on page 23.
ENWW Load a roll into the printer 21
Handle the substrate
