65W AC Adapter
65W AC Adapter65W AC Adapter
65W AC Adapter
Dimensions
DimensionsDimensions
Dimensions
4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm)
Weight
WeightWeight
Weight
0.62 lb (280 g)
Input
InputInput
Input
100 to 240 VAC
Input Efficiency
83% min at 115 VAC
Input frequency range
47 to 63 Hz
Input AC current
1.7 A at 90 VAC, 0.85 A at 180 VAC
Output
OutputOutput
Output
Output power 65W
65W
DC output
18.5V
Hold-up time
5 msec at 115 VAC input
Output current limit
<5A, Over voltage protection- 29V max
automatic shutdown
Connector
ConnectorConnector
Connector
3 pin/grounded, mates with interchangeable cords
Environmental Design
Environmental DesignEnvironmental Design
Environmental Design
Operating temperature
32° to 104° F (0° to 40° C)
Non-operating (storage)
temperature
-4° to 149° F (-20° to 65° C)
Altitude
0 to 10,000 ft (0 to 3,048 m)
Humidity
20% to 80%
Storage Humidity
10% to 90%
EMI and Safety
EMI and SafetyEMI and Safety
EMI and Safety
Certifications
CertificationsCertifications
Certifications
CE Mark - full compliance with LVD and EMC directives; Worldwide safety
standards - IEC950, EN60950, UL1950, Class2, SELV; Agency approvals -
C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22
Class B, CCIB, NOM-1 NYCE; MTBF - over 200,000 hours at 25°C
ambient condition.
32 WHr Primary 4-Cell
32 WHr Primary 4-Cell32 WHr Primary 4-Cell
32 WHr Primary 4-Cell
Battery
BatteryBattery
Battery
Dimensions
DimensionsDimensions
Dimensions
(H x W x L)
0.8 x 1.6 x 10.6 in (2.4 x 4.0 x 26.9 cm)
Weight
WeightWeight
Weight
0.50 lb (0.225 kg)
Cells/Type
Cells/TypeCells/Type
Cells/Type
4-cell Lithium-Ion
Energy
EnergyEnergy
Energy
Voltage
14.4 V
Watt-hour Capacity
32Wh
Amp-hour Capacity
2.2Ah
Temperature
TemperatureTemperature
Temperature
Operating (Charging)
32° to 113° F (0° to 45° C)
Operating (Discharging)
14° to 140° F (–10° to 60° C)
Non-operating
–4° to 140° F (–20° to 60° C)
Battery Re-Charge Time
Battery Re-Charge TimeBattery Re-Charge Time
Battery Re-Charge Time
System in OFF mode or
Standby
2.5 hours
System ON
3 to 5 hours (depending on system power
consumption)
HP Fast Charge
Charges the battery up to 90% within 1.5 hours
when system is OFF
QuickSpecs
HP 530 Notebook PC
HP 530 Notebook PCHP 530 Notebook PC
HP 530 Notebook PC
Technical Specifications
DA - 12722 North America — Version 14 — July 14, 2008
Page 11
