LaserJet 8150HN
HP Parts Reference Guide™
www.h
.com/
o/h
arts
Mailbox Components
Bin
241
C3764-60505 Face up output bin - Top bin on multi-bin mailbox
242
C4785-60502 Single paper output bin - For the multi-bin mailbox assembly
Cable
243
C4787-60507 Stapler unit C-link cable - Has two high density 15 pin (M) connectors - 91.4cm (36 inches) long
Caster
244
C4785-60510 Fixed caster - Non-adjustable height caster
245
C4785-60511 Fixed caster - Adjustable height caster
Clip
246
C4785-60512 Multibin mailbox attachment clip
Cover
247
C3764-60555 Top cover
248
C4785-60503 Blind cover - Covers space trays and face-up bin - Home position cover for head assembly
249
C4785-60504 Front cover - Front side cover
250
C4785-60505 Side cover - Back side cover
Extension
C4785-60531 C-link cable adapter extension - Used when no input device is used with 8-bin or 5-bin mailbox
Flipper
252
C4785-60540 Flipper assembly (with cable) - Moves paper from printer to face down mailbox tray or the face up bin on top - Includes
firmware chip
Guide
253
C3764-60561 Paper input guide - Mounted in top of multi-bin mailbox
Head Assembly
254
C4785-60523 Head assembly - Moves paper up and down the mailbox to the correct mailbox bin
Kit
C4785-60513 Repackaging kit
256
C4785-60516 Attachment kit - Attachment rod, bracket and cables
257
C4785-60519 Plastic parts kit - Contains paper anticurl spring/strings, small bottom pulley, flat cable holder, edge and gasket
258
C4785-60520 Cable kit - Includes interlock switch, head motor cable, flipper sensor, encoder, motor controller cables, ESD cable, and
delivery head assembly flat cable
LED
259
C4785-60515 Status LED display - With cable
Lock
C4787-60503 Shipping lock kit - For 8-bin and 5-bin mailboxes
Mailbox
261
C4787-69506 5-bin mailbox - Used when stapler option is present
REQUIRES RETURN OF DEFECTIVE PART
C4787-60510 New Part for C4787-69506
Motor
C3764-60507 Elevator stepper motor
263
C4785-60518 Transport belt motor - Includes fan
PC Board
264
C4785-60514 Diagnostic LED display board - With cable
C4785-60539 Mailbox contoller PCA
© 2004 Hewlett-Packard 11
