FENIX IMVICO
TK14 OPERATION MANUAL
40/65
GS H
n
[Name] Select print position for HRI characters.
[Format] ASCII GS H
n
Hex 1D 48
n
Decimal 29 72
n
[Range]
n
= 0/3
[Description] Selects the print position of HRI characters when printing a bar code.
n
selects the print position as follows:
n
Printing position
0 Not printed
1 Above the bar code
2 Below the bar code
3 Both above and below the code bar
[Notes]
•
HRI indicates Human Readable Interpretation
•
HRI characters are printed using X-scale = 1, Y-scale = 1 and the font specified by
GS f.
[Default]
n
= <02>H
[Reference]
GS f, GS k
GS h
n
[Name] Select bar code height
[Format] ASCII GS h
n
Hex 1D 68
n
Decimal 27 104
n
[Range] <01>H
≤
n
≤
<FF>H
[Description] Selects the height of the bar code.
n
specifies the bar code height in the vertical direction [
n
x 0.0625 mm (0.0049”)].
[Default]
n
= <A0>H (10mm)
[Reference]
GS k
GS k
m n d1...dn
[Name] Print bar code
[Format] ASCII GS k
m n d
1...
dn
Hex 1D 6B
m n d
1...
dn
Decimal 27 107
m n d1...dn
[Range] m= <43>H , m = <45>H, m= <46>H or m= <49>H
(n
and
d
depend on the bar code system used).
[Description] Selects a bar code system and prints the bar code.
m
selects a bar code system as follows:
m
Bar Code System Number of Characters Remarks
<43>H EAN13
n
= <0C>H
<30>H
≤
d
≤
<39>H
<45>H CODE39
<01>H
≤
n
≤
<FF>H <30>H
≤
d
≤
<39>H, <41>H
≤
d
≤
<5A>H, <20>H, <24>H, <25>H,
<2B>H, <2D>H, <2E>H, <2F>H
<46>H ITF
<01>H
≤
n
≤
<FF>H
(even number)
<30>H
≤
d
≤
<39>H
<49>H Code128
<02>H
≤
n
≤
<FF>H <00>H
≤
d
≤
<7F>H
[Notes]
•
n
indicates the number of bar code data bytes, and the printer processes
n
bytes from
the next character data as bar code data.
•
If
n
is outside the specified range, the printer stops command processing and
processes the following data as normal data.
•
If
d
is outside the specified range, the printer only feeds paper and processes the
following data as normal data.
•
If the horizontal size exceeds printing area, the printer only feeds the paper.
•
This command feeds as much paper as is required to print the bar code, regardless of
the line spacing specified by
ESC 2
or
ESC 3
.
