Installation
Installing the Hardware
Version 1.03
2-3
It is also necessary to connect the NetPorty II with a
power supply. Therefore an external power unit can be
used to supply the NetPorty II via the power connector
or via the 9 Pin D-Sub CAN-connector.
If all connections are done NetPorty II is operational and
the next step is the software installation.
CAN
Power
su
pp
l
y
Centronics
Serial
R
S
2
3
2
