3-50 Cisco IGX 8400 Series Installation and Configuration

IGX Configuration Summary

— Set up any subrate trunk interface control templates if desired (cnftrkict).

• For setting up voice lines:

— Activate the line (upcln or upln).

— Conﬁgure the line (cnﬂn). If you use cnﬂn to conﬁgure the line for voice SVC caching in

conjunction with VNS, see to the VNS documentation for a description of this service and

the CVM or UVM description in the Cisco IGX 8400 Series Reference for line-information.

— Conﬁgure redundancy (addyred).

• For setting up data lines and ports:

— Activate the line (upcln).

— Conﬁgure the line (cnfcln).

— Conﬁgure redundancy (addyred).

• Set up Frame Relay lines and ports. (See the section “Setting Up Frame Relay Ports and

Connections (UFM)” or “Setting Up Frame Relay Ports and Connections (FRM)” for a

description.)

— Activate each port (upfrport).

— Specify a mode for the card as needed if the card is a UFM-U (cnfmode). To determine the

current mode of a particular UFM-U, use dspmode.

• For setting up ATM lines and ports:

— Activate the line (upln).

— Conﬁgure the line (cnﬂn).

— Activate the ports (upport).

— Conﬁgure the ports (cnfport)

— For a UXM-E, specify cellbus bandwidth as needed (cnfbusbw—a superuser command).

• For setting up voice connections:

— Add the connections (addcon).

— Conﬁgure connection parameters (cnfvchadv, cnfchdl, cnfchec, cnfchgn, cnfcond,

cnfcondsc, cnfrcvsig, cnfsmtsig, cnfvchtp, cnfchutl)

— For only the UVM, additional conﬁguration commands you can use are: (cnfuvmchparm,

cnfchfax, cnﬂnpass. (Use dsplncnf to check whether the port is conﬁgured for External,

Pass-through, Blocking, or Inserting.)
