Advanced Secure 8-Port and 16-Port DVI-I KVM
Part No.: F1DN108C, F1DN108F, F1DN116C
Enclosure: SPCC steel-metal enclosure with
aluminum faceplate
Power Requirements: 100–240VAC, 0.9A Max, 50/60Hz
AC Input: 100 to 240VAC
No. of Users Supported: 1
No. of Computers Supported: 8 (F1DN108C, F1DN108F), 16 (F1DN116C)
Monitors Supported: Single-Link and Dual-Link digital DVI-D
displays; analog VGA monitors
with adapter
Resolution Support: Up to 2560x1600
Console Keyboard Input: USB Type A
Console Mouse Input: USB Type A
Console CAC Input: USB Type A
Console Monitor Port: DVI-I Dual-Link female
Console Speaker: 3.5mm female
CPU Keyboard/Mouse Ports: USB Type B
CPU CAC Ports: USB Type B
CPU Keyboard/Mouse Ports: USB Type B
CPU Audio: 3.5mm female
CPU Monitor Ports: DVI Dual-Link female
Port Selectors: 8 and 16 respectively for 8-
and 16-port models
LED Indicators: 8 and 16 respectively for 8-
and 16-port models
Operating Temp: 32° to 104° F (0° to 40° C)
Storage Temp: -4° to 140° F (-20° to 60° C)
Humidity: 0-80% RH, non-condensing
Warranty: 3 years
Specifications
