The touch button control panel located on the top side of the
AVerVision300p provides quick access to commonly used functions.
PLAYBACK
PC
CAMERA
EFFECT
VGA/
TV
MENU
ZOOM
FREEZE CAP/DEL
AVerVision300P
Function Description
(1) CAMERA
MODE
Switch to Camera mode and display the image from the
AVerVision300p’s built-in CMOS camera.
(2) PC MODE
Switch to PC mode and display the video signal from the RGB
input port.
(3) PLAYBACK
MODE
Switch to Playback mode and toggle to display 80-thumbnail
images.
(4) VGA/TV
Switches between VGA (VGA Out) or TV (Composite
Video/S-Video Out).
(5) EFFECT
Convert and display the video in BW, Negative or Color. (camera
mode only)
(6) FREEZE
Toggle to pause or resume the camera.
(7) CAP/DEL
Photograph an image. The captured image is automatically
stored in the memory source at 1024 x 768 resolution.
AVerVision300p could save up to 80 images.
In Playback Mode, press this button to delete the saved image.
(8) MENU
Call up and exit the OSD main and sub-menu.
