23
REMOTE START FEATURE PROGRAMMING:
START FEATURE “D” PROGRAMMING:
1. Turn the Ignition ‘switch ‘ON/OFF’ 3 TIMES and stay in OFF
position.
2. Push the Valet switch 9 times (holding in on the 9TH push) until four
chirps with a long chirp is heard then release the valet switch. You are
now in the Start feature ‘D’ programming mode.
3. Press and release the transmitter button corresponding to the feature
you want to program.
Transmitter
Button
LED one pulse
Factory Default
Setting
LED two pulse
LED three
pulse
LED four
pulse
1
Exit the programming mode.
(3 long chirp & 3 parking light flashes to confirm this exit.)
2 +
Tachometer
Check type (3A)
Voltage check
type (go to 3B)
checking type
(go to 3B)
3
see RPM Learning page 23.
B> Start Crank
Time:
0.6-second
1.2-second (4 chirps), 1.4-second (5 chirps),
1.6-second (6 chirps), 1.8-second (7 chirps),
2.0-second (8 chirps), 3.0-second (9 chirps),
4.0-second (10 chirps),
4
Low check level Hi check level
5
Start or Stop the system for TESTING & ADJUSTMENT
6 +
Door Trigger
P/S# (zone 4)
7 +
DBI ONLY
No RPM learning
8 +
- 50 RPM
DBI ONLY
Learning or <
50RPM
Exit: Press the button on the transmitter. 3 long chirps & 3 parking
light flashes will confirm exit.
TACHOMETER CHECKING TYPE:
Enter Start Feature ‘D’ Programming Mode:
1. Turn the Ignition ‘switch ‘ON/OFF’ 3 TIMES and stay in OFF position.
2. Push the Valet switch 9 times (holding in on the 9th push) until four
chirps with a long chirp is heard then release the valet switch. You are
now in the Start feature ‘D’ programming mode.
Select “Checking Type”:
3. Press and release the transmitter + button once to set the
“Tachometer Checking Type”. [1] LED flash, [1] Siren chirp to confirm
