3.7 PC Health Status
Phoenix – AwardBIOS CMOS Setup Utility
PC Health Status
►
ABIT FanEQ Control Press Enter Item Help
FAN Fail Alarm Selectable Disabled
Shutdown When FAN Fail Disabled
CPU Shutdown Temperature Disabled
CPU Warning Temperature 85
°
C/ 185
°
F
CPU Temperature 35
°
C/ 95
°
F
System Temperature 32
°
C/ 89
°
F
PWM Temperature 35
°
C/ 95
°
F
CPU FAN Speed 3245 RPM
SYS FAN Speed 4218 RPM
AUX1 FAN Speed 0 RPM
AUX2 FAN Speed 0 RPM
CPU Core Voltage 1.25V
DDR2 Voltage 1.88V
DDR2 VTT Voltage 0.93V
PCIe Voltage 1.75V
ATX +12V 11.98V
ATX +5V 5.20V
ATX +3.3V 3.29V
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
ABIT FanEQ Control
This item determines the temperature threshold to raise the fan attached at CPU and SYS fan
headers up to their full speed.
Click <Enter> key to enter its submenu:
Phoenix – AwardBIOS CMOS Setup Utility
ABIT FanEQ Control
CPU FanEQ ontrol Enabled Item Help
- FanEQ Target Temp. 50
°
C/122
°
F
- FanEQ Temp. Tolerance 5
°
C/ 41
°
F
- FanEQ Start Control 80%
- FanEQ Stop Control 50%
SYS FanEQ Control Enabled
- FanEQ Target Temp. 35
°
C/ 95
°
F
- FanEQ Temp. Tolerance 5
°
C/ 41
°
F
- FanEQ Start Control 70%
- FanEQ Stop Control 50%
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
