CoreBuilder 74XX Ethernet/ATM Interface Card
7400 Ethernet/ATM interface card with
■
24 Ethernet ports (2 RJ-21 connectors)
■
ATM interface receptacle unoccupied
3C37400 4.5
7412 Ethernet/ATM Expansion Module with
■
12 Ethernet ports (1 RJ-21 connector)
■
ATM interface receptacle unoccupied
3C37412 3.6
7436 Ethernet/ATM Expansion Module with
■
36 Ethernet ports (3 RJ-21 connectors)
■
ATM interface receptacle unoccupied
3C37436 8.1
CoreBuilder 76XX Fast Ethernet Interface Card
7600F Fast Ethernet Interface Card with
■
16FX Fast Ethernet ports
3C37600 23.4
7608F Fast Ethernet Interface Card with
■
8FX Fast Ethernet ports
■
8 Fast Ethernet ports unoccupied
3C37608 16.2
7660F Fast Ethernet Interface Card with
■
2FX Fast Ethernet ports
■
14 Fast Ethernet ports unoccupied
3C37660 1.8
7600T Fast Ethernet Interface Card
■
16TX Fast Ethernet ports
3C37601 20.7
7608T Fast Ethernet interface card
■
8TX Fast Ethernet ports
■
8 Fast Ethernet ports unoccupied
3C37617 15.3
7662T Fast Ethernet module
■
2TX Fast Ethernet ports
■
14 Fast Ethernet ports unoccupied
3C37662 1.4
* The typical power consumption values represent typical traffic, load and line speed of the
CoreBuilder and interface cards
.
Maximum power consumption of the cards is 10% higher
than the typical values, and occurs when all card ports are working at full rate
† A redundant switch has the same power requirements as the active switch
Table 20
Typical Power Consumption of CoreBuilder 7000 Family Cards
