Specifications
Calibration period: six months minimum. Specifications apply at 23°C ± 5°C, < 80% RH
Accuracy = ± (% of reading + number of digits)
Temperature Coefficient = Accuracy 0.1/° C (0° C to 18° C; 28° C to 55° C)
General
Do not expose product to moisture or rain. Do not use product in flammable atmosphere.
Operating Temperature: 0° to 40°C / 80% RH max (no condensation).
Storage Temperature: -25°C to 60°C / 20% to 70°C RH (no condensation).
Display reading rate: Approximately 2 — 4 times/second
Display rate for frequency measurements: Approximately 1 times/second
Battery life: Approximately 120 hours on DCV
DC Voltage
Range Resolution Accuracy Input Resistance
500 mV
10 µV
± (0.05% + 2)
> 1000 MΩ
5 V
100 µV
11 MΩ (nominal)
50 V 1 mV
10 MΩ (nominal)
500 V 10 mV
1000 V 100 mV
Normal Mode Rejection Ratio: (NMR) > 60 dB @ 50 or 60 Hz
Effective Common Mode Rejection Ratio (CMR) 1 kΩ imbalance: > 120 dB @ 50 or 60 Hz
AC Voltage (RMS responding, calibrated to display rms)
Range Resolution
Accuracy
Input
Impedance
(nominal)
20 Hz to
50 Hz
50 Hz to
10 kHz
10 kHz to
30 kHz
30 kHz to
50 kHZ
50 kHz to
100 kHz
500 mV
10 µV
± (1% + 30)
± (0.7% +30) ± (2% + 50)
Not Specified
11 M Ω
< 50 pF
5 V
100 µV
± (0.5% + 30) ± (1% + 40) ± (2% + 70) ± (3% + 300)50 V 1 mV
10 M Ω
< 50 pF
500 V 10 mV
750 V 100 V
± (1% + 30) 20 Hz to 1 kHz
Not Specified
1-17
